7" LCD Screen
Part: LCD-7
This 7" Pro HD LED Monitor is designed to be used as an external video display, allowing you to step back from the camera while still being able to frame and capture the action without having to look through the cameras built-in viewfinder. It employs advanced integrated circuits and high quality TFT LCD modules, low comsumption, steady function, and low radiation emission. This small-sized design is easy and safe to operate, with HDMI INPUT, HDMI OUTPUT (Optional), COMPONENT, COMPOSITE VIDEO,
AUDIO INPUTS, this monitor can be easily be installed on Digital Camera DSLR, the best partner for photography.
Features:
- Frame shots from a distance
- Comes with Aussie DC power plug. Also can be powered by Sony style batteries F970 and QM91D (not included)
- Small and portable
- Great for use with a crane or jib
Includes:
1 x 7" LCD Screen
1 x DC12V DC power adapter
1 x HDMI cable
1 x Sun shade
1 x Hot shoe mount
1 x User manual
Specifications:
Display panel - TFT LCD 7.0inch 1152000 Pixels
Resolution - 800×480
Max resolution - 1920×1440
Brightness - 400 cd/m2 ～ 450 cd/m2
Contrast - 500:1
Viewing angle - 70°/70°, 50°/60° (L/R, U/D)
Video signal input range - 0.7～1.4Vp-p/75Ω
Supported input frequency - H:30～60kHz, V:60～75Hz
HDMI & YPbPr supported format - 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Speaker output power - ≥1W/8Ω
Video color system - PAL-4.43; NTSC-3.58
Backlight - LED
Signal input - HDMI, YPbPr, VIDEO1, VIDEO2, AUDIO
Power voltage - DC6V-12V
Power consumption - ≤8w
Standby current - ≤50mA
Working temperature - -20～55℃
Storage temperature - -30～65℃
Unit size - 188.4mm x 131mm x 40mm
